QualiShear-2 Direct Shear Test Machine – Soil Shear Strength

SKU QualiShear-2
Original price $6,499.00 - Original price $6,499.00
Original price
$6,499.00
$6,499.00 - $6,499.00
Current price $6,499.00
Availability:
10 in stock, ready to be shipped
Secure Payment
Free Shipping NZ-Wide
30-Day Returns
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • Shop Pay
  • Union Pay
  • Visa
Request A Quote (For Bulk Orders)
Shipping information

Qualitest products ship internationally from the United States directly to your New Zealand address. Most orders dispatch within 5-10 business days of order placement. Estimated delivery to New Zealand is 10-20 business days from dispatch, depending on freight mode, customs clearance, and carrier schedules.

Delivery timeframes for larger or heavier items may vary. Some products may be subject to extended lead times depending on stock availability at the time of order. For time-sensitive orders, contact us before purchasing to confirm current lead time.

Free shipping applies to all orders. Prices displayed are exclusive of GST. GST will be added at checkout and all import and customs costs are managed by TestingCore - there are no additional charges on delivery.

Returns & warranty

Qualitest products are covered by manufacturer warranties against defects in materials and workmanship. Warranty periods vary by product - many instruments in the Qualitest range carry a 12-month manufacturer warranty, and selected products such as the Qualitest CMX ultrasonic thickness gauge series carry a 2-year warranty. Contact us for specific warranty details for the product you are purchasing.

Returns are accepted within 30 days of delivery for products in original, unused condition with all original packaging and accessories intact. Due to the international nature of these shipments, return freight costs are the responsibility of the buyer unless the item arrived damaged or was incorrectly supplied. Items that have been used, installed, calibrated, or modified are not eligible for return.

For warranty claims or return requests, contact us at sales@testingcore.com or call 09 558 3100.

This direct shear test machine measures the shear strength of soil - a figure that matters for designing foundations, retaining walls, bridge slabs, pipelines, and sheet piling structures. Getting an accurate read on properties like internal friction angle and cohesion is critical for good design, and the direct shear test is a fast, reliable way to get there.

The QualiShear-2 is a lightweight, hand-operated take on the direct shear apparatus, built for portable, field-deployable soil testing with no electrical power needed.

  • Hand-cranked, fully manual operation - no electrical power needed
  • Lightweight and portable, ready for field deployment
  • 1:12 mechanical lever ratio keeps shear force consistent
  • First-grade hanger system for vertical load weights
Soil Sample Area 30 cm² x 2cm (H)
Vertical Load Options 50, 100, 200, 300, 400 kPa
Lever Ratio 1:12
Max Shear Force 1.2 kN
Power Source Manual (hand-operated)
Corresponding Weights 1.275, 2.55, 5.1, 7.65, 10.2 kg
Hanger System First-grade quality
Standards Compliance AASHTO T236, ASTM D3080, BS 1377-7, NF P094071-1/2
